Specifications
General Specifications
Frost Free: Yes
Annual Energy (kWH): 647
Condenser Type: Dynamic
Sound Package: Quiet Pack
Water Inlet Location: Left Rear Bottom
Shipping Weight (lbs): 300
Product Weight (lbs): 287
Made In USA: No
Power Type: Electric
Size: 26 Cu. Ft.
Installation Type: Free-Standing
Collection: Frigidaire Gallery
Capacities
Capacity (Cu. Ft.): 25.6
Fresh Food Capacity (Cu. Ft.): 16.54
Freezer Capacity (Cu. Ft.): 9.03
Total Shelf Area (Sq. Ft.): 24.8
Fresh Food Shelf Area (Sq. Ft.): 18.7
Freezer Shelf Area (Sq. Ft.): 6.1
Dispenser
Dispenser Type: Flush Single Paddle
Crushed Ice: Yes
Cube Ice: Yes
Water: Yes
Dispenser Light: Yes
Display On/Off: Yes
Certifications & Approvals
ENERGY STAR® Certified: Yes
Sabbath Mode (Star-K® Certified): Yes CSA Certified: Yes ADA Compliant: Yes
Exterior Specifications
Door Design: Tall
Door Style: Curved Door
Name Badge: Gallery
Handle Design: Gallery
Door Hinge Covers: Hidden
Cabinet Finish: Textured
Cabinet Color: Grey
Toe Grille: Grey
Front Rollers: Adjustable
Rear Rollers: Yes
Door Gasket: Grey
Door Stops: Yes
Door Closers: Yes
Ice Maker
Ice Maker: Yes
Ice Maker On/Off: Yes
Electrical Specifications
Voltage Rating: 120V 60Hz
Amps @ 120 Volts: 8.5
Minimum Circuit Required (Amps): 15A
Connected Load (kW Rating) @ 120V: 1.02
Power Supply Connection Location: Right Rear Bottom
Controls
Controls: Express-Select®
Control Location: Dispenser
Control Buttons: 11
Water Filter Change Indicator Light: Yes
Air Filter Change Indicator Light: Yes
Freezer Specifications
Freezer Lighting: Bright
Fixed Freezer Shelves: 2 Wire
Pizza Shelf: Yes
Ice Cream Shelf: Yes
Full-freezer Baskets: 1 Plastic 1 Wire
Fixed Door Bins: 4 White
Fresh Food
Energy Saver Plus: Yes
Door Ajar Alert: No
Temperature Alert: Yes
Power Failure Alert: Yes
Lighting Design: Bright
Lighting Levels: Dual-Level
Water Filter: PureSource® Ultra
Water Filter Location: Top Right Rear
Air Filter: PureAir Ultra®
Air Filter Location: Rear
Cantilever Shelves: Yes
Sliding Shelves: 2 SpillSafe®
Fixed Shelves: 1 SpillSafe®
Upper Crisper: Clear
Lower Crisper: Clear
Humidity Controls: 2
Meat / Deli Drawer: Stacked Deli
1-Gallon Adjustable Door Bins: 2 Clear
Fixed Door Bins: 2 Two-Liter Clear
Dairy Compartment: Clear
Drawer Trim: Yes
Drawer Trim Color: White
Controls Style & Color
Controls: Capacitive Touch
Exterior Dimensions
Height: 69-7/8″
Width: 36″
Depth: 33-3/8″
Case Height: 68-5/8″
Height with Hinges and Covers: 69-7/8″
Case Width: 35-7/8″
Case Depth: 28-3/4″
Depth with Doors (no Handles): 33-3/8″
Depth with Doors and Handles: 35-7/8″
Depth (with Door 90° Open): 50″
Height to Top of Door: 70-1/8″
Width between Door Edges: 36″
Part Replacements
Water Valves 242252702
hoses are all 5/16″
Replaced water dispenser hoses 11/14/2017
